SAME Explorer 90C


SAME Explorer 90C tractor photo
Explorer Series
Agricultural Crawler tractor
Series map:
Explorer 80C
Explorer 90C
59.7kw
65.6kw
Production
ManufacturerSAME
Agricultural Crawler tractor
SAME Explorer 90C Engine
SAME 4.0L 4-cyl diesel
Fuel tank39.6 gal
149.9 L
Engine details ...
SAME Explorer 90C Power
Engine88 hp
65.6 kW
PTO (claimed)76 hp
56.7 kW
Mechanical
Drivecrawler
Final drivesspur gear
Band brakes
Four-post ROPS.
Photos
No photos of the SAME Explorer 90C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2538 psi
175.0 bar
Valves3
Pump flow10.6 gpm
40.1 lpm
Tractor hitch
Rear TypeII
Controltop-link draft sensing
Rear lift (at ends)6393 lbs
2899 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear RPM540/1000
Dimensions & Tracks
Wheelbase64.8 inches
164 cm
Weight10590 lbs
4803 kg
15.7-inch tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
References
Explorer 90C references literature
Explorder 70-80-90 C Ergomatic published in 2003, by SAME
