Tractors > SAME > Explorer 80C

SAME Explorer 80C

SAME Explorer 80C tractor photo
Explorer Series
Agricultural Crawler tractor
Series next:SAME Explorer 90C
Series back:SAME Explorer 70C






Production:

Manufacturer:SAME


SAME Explorer 80C Engine:

   SAME 4.0L 4-cyl diesel
full engine details ...


Capacity:

Fuel:26.4 gal [99.9 L]


3-Point Hitch:

Rear Type:II
Control:top-link draft sensing
Rear lift (at ends):6393 lbs [2899 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:wet disc
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:64.8 inches [164 cm]
Weight:9259 lbs [4199 kg]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


Explorer 80C Serial Numbers:


how to read serial numbers...



SAME Explorer 80C Power:

Engine:80 hp [59.7 kW]
PTO (claimed):69 hp [51.5 kW]


Mechanical:

Chassis:crawler
Final drives:spur gear
Brakes:band
Cab:Four-post ROPS.


Hydraulics:

Pressure:2538 psi [175.0 bar]
Valves:3
Pump flow:10.6 gpm [40.1 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:55


Battery:

Volts:12
