SAME Frutteto II 60
| | Frutteto Series | | Orchard/Vineyard tractor |
|
| Production |
| Manufacturer: | SAME
|
| Type: | Orchard/Vineyard tractor
|
| SAME Frutteto II 60 Power |
| Engine: | 60 hp
44.7 kW
|
| PTO (claimed): | 52 hp
38.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | inboard planetary
|
| Differential lock: | mechanical
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab optional with air-conditioning.
|
| Transmissions: | 12-speed partially synchronized
|
| | 16-speed creeper
|
 Transmission details ... |
| Photos |
| No photos of the SAME Frutteto II 60 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure: | 2650 psi
182.7 bar
|
| Valves: | 1 to 3
|
| Pump flow: | 8.7 gpm
32.9 lpm
|
| | 16 gpm
60.6 lpm *Optional
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift (at ends): | 6614 lbs
3000 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | dry disc
|
| Rear RPM: | 540/1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| ROPS Charging amps: | 55
|
| Cab Charging amps: | 65
|
| Battery volts: | 12
|
| Battery AH: | 100
|
