Tractors > SAME > Vigneron 62

SAME Vigneron 62

SAME Vigneron 62 tractor photo
Vigneron Series
Orchard/Vineyard tractor
Previous model:SAME Vigneron 60
Series next:SAME Vigneron 75






Production:

Manufacturer:SAME


SAME Vigneron 62 Engine:

   SAME 3.0L 3-cyl diesel
full engine details ...


Capacity:

Fuel:12.7 gal [48.1 L]


3-Point Hitch:

Rear Type:II/I
Rear lift (at ends):5511 lbs [2499 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:dry disc
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:74.5 inches [189 cm]
Weight:4300 lbs [1950 kg]
Front tire:9.0/75x16
Rear tire:13.6R24
full dimensions and tires ...


Vigneron 62 Serial Numbers:


how to read serial numbers...



SAME Vigneron 62 Power:

Engine:60 hp [44.7 kW]
PTO (claimed):52 hp [38.8 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:mechanical front and rear
Steering:power
Brakes:mechanical wet disc
Cab:Two-post mid-mount folding ROPS.


Hydraulics:

Pressure:2650 psi [182.7 bar]
Valves:1 to 3
Pump flow:9.2 gpm [34.8 lpm]
 16 gpm [60.6 lpm] *Optional


Electrical:

Ground:negative
Charging system:alternator
Charging amps:55


Battery:

Volts:12
Amp-hours:100
