CaseIH Maxxum 135 MultiController


CaseIH Maxxum 135 MultiController tractor photo
2015 -
Maxxum Series
Utility tractor
Production
Manufacturer:CaseIH
Type:Utility tractor
Original price:$125,650 (2017 Power shift )
Original price:$144,234 (2017 CVT )
Variants
Maxxum 135:standard
Maxxum 135MC:premium
CaseIH Maxxum 135 MultiController Power
Engine (gross):135 hp
100.7 kW
Engine (max):169 hp
126.0 kW
PTO (claimed):110 hp
82.0 kW
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:inboard planetary
Steering:power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with air-conditioning.
Transmissions:16-speed partial power shift
 continuously-variable transmission (CVT)
Transmission details ...
Photos
No photos of the CaseIH Maxxum 135 MultiController are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:51.5 gal
194.9 L
 57.5 gal
217.6 L *Optional, with auxiliary tank.
 60.8 gal
230.1 L *Optional, max tank.
Exhaust fluid (DEF):10.4 gal
39.4 L
Hydraulic system:19.5 gal
73.8 L
Hydraulics
Type:pressure flow compensated
Capacity:19.5 gal
73.8 L
Rear valves:3 or 4
Mid valves:0 to 3
Pump flow:29.8 gpm
112.8 lpm
 33 gpm
124.9 lpm *With CVT transmission.
SCV flow:25.1 gpm
95.0 lpm (mechanical)
 26.5 gpm
100.3 lpm (electronic)
Total flow:42.4 gpm
160.5 lpm
 45.5 gpm
172.2 lpm *With CVT transmission.
Steering flow:12.4 gpm
46.9 lpm
Tractor hitch
Rear Type:II
 IIIN/II*Optional
Control:electronic lower-link draft sensing
Rear lift (at 24"/610mm):6900 lbs
3129 kg
 7700 lbs
3492 kg *Optional
Rear Arms:telescopic link ends
Front Hitch:optional
Drawbar:Cat. 3
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000 (1.375)
Front PTO:independent*Optional
Clutch:1000:1895
Front RPM:1000 (1.375)
Dimensions & Tires
Wheelbase:104 inches
264 cm
 106.2 inches
269 cm *With front-axle suspension.
Weight:11300 lbs
5125 kg
Front tire:380/85R28
Rear tire:460/85R38
Full dimensions and tires ...
Electrical
Charging amps:120
 150*Optional
 200*Optional
Battery CCA:1300
Battery volts:12
Battery AH:176
