Tractors > Zetor > Proxima 90

Zetor Proxima 90

Zetor Proxima 90 tractor photo
2011 - 2016   Proxima Series
Model years
Utility tractor
Previous model:Zetor Proxima 85
Series next:Zetor Proxima 100
Series back:Zetor Proxima 80






Production:

Manufacturer:Zetor
Factory:Brno, Czech Republic


Zetor Proxima 90 Engine:

   Zetor 4.2L 4-cyl diesel
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:II
Control:position control and mechanical top-link draft sensing
Rear lift:9442 lbs [4282 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000
 540/540E
Front RPM:1000


Dimensions & Tires:

2WD Wheelbase:91.4 inches [232 cm]
4WD Wheelbase:88 inches [223 cm]
Weight:6900 to 8003 pounds
Front tire:7.5-16
2WD Rear tire:16.9-28
full dimensions and tires ...


Proxima 90 Serial Numbers:


- Serial numbers unknown -



Zetor Proxima 90 Power:

Engine (net):87 hp [64.9 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with optional air-conditioning.


Hydraulics:

Pressure:2611 psi [180.0 bar]
Valves:1
Total flow:13.2 gpm [50.0 lpm]


Electrical:

Charging system:alternator
