New Holland T8.410 SmartTrax


New Holland T8.410 SmartTrax tractor photo
2015 -
T8 Series
Half-track Crawler tractor
Series map:
T8.380 SmartTrax
T8.410 SmartTrax
T8.435 SmartTrax
311.0hp
340.0hp
380.0hp
Production
ManufacturerNew Holland (a part of CNH)
Half-track Crawler tractor
Original price was $396,566 in 2016 with powershift
Variants
T8.410wheeled tractor
T8.410 SmartTraxhalf-track
New Holland T8.410 SmartTrax Engine
FPT 8.7L 6-cyl diesel
CVT Fuel tank163 gal
617.0 L
FPS Fuel tank179 gal
677.5 L
Exhaust fluid (DEF)26 gal
98.4 L
Engine details ...
New Holland T8.410 SmartTrax Transmissions
18-speed full power shift
continuously variable transmission (CVT)
Transmission details ...
New Holland T8.410 SmartTrax Power
Engine (gross)340 hp
253.5 kW
Engine (max)409 hp
305.0 kW
PTO (claimed)290 hp
216.3 kW
Drawbar (tested)251.58 hp
187.6 kW
PTO (tested)340.17 hp
253.7 kW
Performance test details ...
Mechanical
Drivehalf-track
Final drivesinboard planetary
Wet disc brakes
Cab standard with air-conditioning. Intellisteer ready
Photos
No photos of the New Holland T8.410 SmartTrax are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure-flow compensating (PFC)
Valves4 to 5
Pump flow43 gpm
162.8 lpm
 73 gpm*Optional, MegaFlow rate.
276.3 lpm
Tractor hitch
Rear TypeIII/IIIN
 IVN/III
Controlelectronic lower-link draft sensing
Rear lift19900 lbs
9026 kg
DrawbarCat. 4
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
 540/1000 OptOptional
Front PTOindependent OptOptional
Front PTO Type1000 (1.375)
Dimensions & Tires
Wheelbase140 inches
355 cm
Weight35788 lbs
16233 kg
Front tire380/80R42
Rear tire18-inch
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery volts12
References
T8.410 SmartTrax references literature
Genesis T8 Series Tractors published in 2015, by New Holland
