Challenger MT575E Tests
|
|
| Tractor Tests | |
| OECD 2936: diesel CVT 4WD | |
| OECD 2935: diesel AutoPower VI 4WD |
| OCED Tractor Test 2936 | |||
| |||
| OCED Tractor Test 2936 | |
| Diesel CVT 4WD November 2016 - January 2016, Link: OCED Tractor Test 2936 file | |
| PTO performance | |
| Max power | 205.2 hp 153.0 kW |
| Fuel use | 11.6 gal/hour 43.9 l/hour |
| Power at rated engine speed | 184.7 hp 137.7 kW |
| Fuel use | 11.4 gal/hour 43.1 l/hour |
| Power at rated PTO speed | 205.2 hp 153.0 kW |
| Fuel use | 11.6 gal/hour 43.9 l/hour |
| Drawbar performance | |
| Max power | 142.8 hp 106.5 kW |
| Fuel use | 11.4 gal/hour 43.1 l/hour |
| Pull at 7.76KPH | |
| Max pull | 16590 lbs 7525 kg |
| Pull at 2.64KPH | |
| OCED Tractor Test 2935 | |||
| |||
| OCED Tractor Test 2935 | |
| Diesel AutoPower VI 4WD September 2015 - November 2015, Link: OCED Tractor Test 2935 file | |
| PTO performance | |
| Max power | 201.8 hp 150.5 kW |
| Fuel use | 10.9 gal/hour 41.3 l/hour |
| Power at rated engine speed | 176.2 hp 131.4 kW |
| Fuel use | 10.6 gal/hour 40.1 l/hour |
| Power at rated PTO speed | 192.0 hp 143.2 kW |
| Fuel use | 11.0 gal/hour 41.6 l/hour |
| Drawbar performance | |
| Max power | 146.3 hp 109.1 kW |
| Fuel use | 10.8 gal/hour 40.9 l/hour |
| Gear 3B used for power test. | |
| Max pull | 15535 lbs 7046 kg |
| Gear 1C used for pull test. | |
