| | Production: |
| Manufacturer: | AGCO
|
| | |
| AGCO Power 4.9L 4-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 67 gal [253.6 L]
|
| Exhaust fluid (DEF): | 7.9 gal [29.9 L]
|
| | |
| Rear Type: | III/II
|
| Rear lift (at 24"/610mm): | 11244 lbs [5100 kg]
|
| Rear Arms: | telescopic link end
|
| | |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| | 540/540E/1000/1000E
|
| | |
| Wheelbase: | 105 inches [266 cm]
|
| Weight: | 15432 lbs [6999 kg]
|
| full dimensions and tires ... | | | MT475E Serial Numbers: |
- Serial numbers unknown -
|
|
|
|
| | Challenger MT475E Power: |
| Engine: | 130 hp [96.9 kW]
|
| PTO (claimed): | 120 hp [89.5 kW]
|
| | Mechanical: |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | electro-hydraulic front and rear
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning. Auto-Guide 3000*Optional
|
| | Hydraulics: |
| Type: | open center
|
| Valves: | up to 5
|
| Pump flow: | 26 gpm [98.4 lpm]
|
| | 29 gpm [109.8 lpm] *Optional
|
| | 50 gpm [189.3 lpm] *Optional
|
| | Electrical: |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 175
|
| | 240*Total charging capacity with optional twin 120A system.
|
| | Battery: |
| Volts: | 12
|
