Iseki TS2420
| | 1979 - 1983 |
| Compact Utility tractor |
|
| Production |
| Manufacturer: | Iseki
|
| Type: | Compact Utility tractor
|
| Variants |
| TS2420: | 2WD
|
| TS2420F: | 4WD
|
| Iseki TS2420 Power |
| Engine: | 24 hp
17.9 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical standard
|
| Steering: | manual
|
| Brakes: | mechanical shoe
|
| Cab: | Open operator station.
|
| Transmission: | 18-speed
|
 Transmission details ... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2000 psi
137.9 bar
|
| Pump flow: | 3.1 gpm
11.7 lpm
|
| Tractor hitch |
| Rear Type: | 1
|
| Control: | Position control
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 540/1000
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | June 23, 2016
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
