Ford 4000 Tests
|
|
| Tractor Tests | |
| NTTL 994: diesel 8-speed 2WD | |
| NTTL 995: diesel Select-O-Speed 2WD | |
| NTTL 999: 201 gasoline Select-O-Speed 2WD | |
| NTTL 1001: 201 gasoline 8-speed 2WD |
| Nebraska Tractor Test 994 | |||
| |||
| Nebraska Tractor Test 994 | |
| Diesel 8-speed 2WD October 30 - November 13, 1968 Link: Nebraska Tractor Test 994 file | |
| PTO performance | |
| Power at rated engine speed | 52.65 hp 39.3 kW |
| Fuel use | 3.4 gal/hour 12.9 l/hour |
| Power at rated PTO speed | 45.94 hp 34.3 kW |
| Fuel use | 2.9 gal/hour 11.0 l/hour |
| Drawbar performance | |
| Max power | 47.57 hp 35.5 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Gear 4 used for power test. | |
| Max pull | 6080 lbs 2757 kg |
| Gear 3 used for pull test. | |
| Nebraska Tractor Test 995 | |||
| |||
| Nebraska Tractor Test 995 | |
| Diesel Select-O-Speed 2WD October 30 - November 18, 1968 Link: Nebraska Tractor Test 995 file | |
| PTO performance | |
| Power at rated engine speed | 51.00 hp 38.0 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Power at rated PTO speed | 44.52 hp 33.2 kW |
| Fuel use | 2.9 gal/hour 11.0 l/hour |
| Drawbar performance | |
| Max power | 45.88 hp 34.2 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Gear 6 used for power test. | |
| Max pull | 6145 lbs 2787 kg |
| Gear 4 used for pull test. | |
| Nebraska Tractor Test 999 | |||
| |||
| Nebraska Tractor Test 999 | |
| 201 gasoline Select-O-Speed 2WD November 11 - 26, 1968 Link: Nebraska Tractor Test 999 file | |
| PTO performance | |
| Power at rated engine speed | 50.16 hp 37.4 kW |
| Fuel use | 4.6 gal/hour 17.4 l/hour |
| Power at rated PTO speed | 45.52 hp 33.9 kW |
| Fuel use | 3.9 gal/hour 14.8 l/hour |
| Drawbar performance | |
| Max power | 42.42 hp 31.6 kW |
| Fuel use | 4.6 gal/hour 17.4 l/hour |
| Gear 6 used for power test. | |
| Max pull | 6112 lbs 2772 kg |
| Gear 4 used for pull test. | |
| Nebraska Tractor Test 1001 | |||
| |||
| Nebraska Tractor Test 1001 | |
| 201 gasoline 8-speed 2WD November 13 - 25, 1968 Link: Nebraska Tractor Test 1001 file | |
| PTO performance | |
| Power at rated engine speed | 52.18 hp 38.9 kW |
| Fuel use | 4.5 gal/hour 17.0 l/hour |
| Power at rated PTO speed | 47.14 hp 35.2 kW |
| Fuel use | 3.9 gal/hour 14.8 l/hour |
| Drawbar performance | |
| Max power | 44.81 hp 33.4 kW |
| Fuel use | 4.6 gal/hour 17.4 l/hour |
| Gear 4 used for power test. | |
| Max pull | 6,096 lbs 2765 kg |
| Gear 2 used for pull test. | |
