Deutz F1L514 50

No photo available
1950 - 1957   FL Series
Model years
Previous model:Deutz F1M414






Production:

Manufacturer:Deutz
Factory:Germany


Deutz F1L514 Engine:

   Deutz 1.3L 1-cyl diesel
full engine details ...


Capacity:

Fuel:7.4 gal [28.0 L]


Power Take-off (PTO):

Rear RPM:540 (1.375)


Dimensions & Tires:

Wheelbase:62.4 inches [158 cm]
Weight:2833 lbs [1285 kg]
Front tire:5.00-16
Rear tire:8.00-32
full dimensions and tires ...


F1L514 Serial Numbers:


- Serial numbers unknown -



Deutz F1L514 Power:

Engine:14.8 hp [11.0 kW]


Mechanical:

Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.


Belt Pulley:

Diameter:8.86 inches [22 cm]
Width:3.94 inches [10 cm]
RPM:1100


Battery:

Volts:12
