CaseIH Farmall 75C


CaseIH Farmall 75C tractor photo
2008 - 2024
Model year
Farmall C Series
Utility tractor
Series map:
Farmall 65C
Farmall 75C
Farmall 90C
64.0hp
74.0hp
86.0hp
Production
ManufacturerCaseIH (a part of CNH)
Utility tractor
Original price$40,237 (2016 mech-shuttle ROPS 4WD )
$50,076 (2016 power-shuttle Cab 4WD )
Variants
PowerStar 75similar New Holland model
CaseIH Farmall 75C Engine
FPT 3.4L 4-cyl
Fuel tank23.8 gal
90.1 L
Engine details ...
CaseIH Farmall 75C Transmissions
8-speed mechanical shuttle
8-speed power shuttle
12-speed power shuttle
Transmission details ...
CaseIH Farmall 75C Power
Engine (gross)74 hp
55.2 kW
PTO (claimed)65 hp
48.5 kW
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Power steering
Wet disc brakes
Two-post ROPS. Cab optional with air-conditioning.
Hydraulics
Typeopen center
Valves1 or 2
Pump flow12.5 gpm
47.3 lpm
Tractor hitch
Rear TypeII/I
Controltop link draft sensing
Rear lift (at ends)4832 lbs
2191 kg
Rear lift (at 24"/610mm)3664 lbs
1661 kg
Rear Armstelescopic link ends
Drawbarswinging drawbar
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 540/540E OptOptional
Dimensions & Tires
2WD Wheelbase85.8 inches
217 cm
4WD Wheelbase83.9 inches
213 cm
Weight5026 to 7338 pounds
Front tire7.50x16
2WD Rear tire16.9R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Battery volts12
References
Farmall 75C references literature
Farmall Utility Series Tractors published in 2021, by CaseIH
