Iseki T10520


Iseki T10520 tractor photo
1990 - 1995
Landmax T20 Series
Utility tractor
Series map:
T9520
T10520
69.9kw
77.3kw
Production
ManufacturerIseki
Utility tractor
Built in Japan
Iseki T10520 Transmissions
12-speed syncromesh
24-speed creeper
Transmission details ...
Iseki T10520 Power
Engine103.6 hp
77.3 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Four-post ROPS. Cab optional.
Photos
No photos of the Iseki T10520 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear RPM540/1000 (1.375)
Dimensions & Tires
Weight8466 lbs
3840 kg
Front tire12.4-24
Rear tire18.4-34
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
