Tractors > John Deere > 9620RX

John Deere 9620RX Tests



John Deere 9620RX tractor photo
2016 - 2021
9R Series
Articulated Crawler tractor
Series map:
9570RX
9620RX
570.0hp
620.0hp
OCED Tractor Test 2174
9620RX fuel use from test 1088
OCED Tractor Test 2174
Diesel 18-speed crawler
April 12 - 19, 2017
Link: OCED Tractor Test 2174 file
PTO performance
Max power357.89 hp
266.9 kW
Fuel use19.4 gal/hour
73.4 l/hour
Power at rated engine speed315.14 hp
235.0 kW
Fuel use19.4 gal/hour
73.4 l/hour
Power at rated PTO speed344.75 hp
257.1 kW
Fuel use19.8 gal/hour
74.9 l/hour
Drawbar performance
Max power494.32 hp
368.6 kW
Fuel use31.8 gal/hour
120.4 l/hour
Gear 7 used for power test.
Max pull48485 lbs
21992 kg
Gear 2 used for pull test.
