New Holland T6.165 Auto Command


New Holland T6.165 Auto Command tractor photo
2015 -
T6 Series
Row-Crop tractor
Production
Manufacturer:New Holland
Type:Row-Crop tractor
Original price:$147,260 (2015 )
Variants
T6.165 Value:economy
T6.165 Plus:mid-spec
T6.165 Elite:premium
T6.165 CVT:AutoCommand
New Holland T6.165 Auto Command Power
Engine:135 hp
100.7 kW
PTO (claimed):110 hp
82.0 kW
New Holland T6.165 Auto Command Engine
FPT 4.5L 4-cyl diesel
Exhaust fluid (DEF):9.7 gal
36.7 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:inboard planetary
Brakes:wet disc
Cab:Horizon cab standard with air-conditioning and Comfort Ride cab suspension. ISOBUS II*Optional
 AutoGuidance*Optional
Transmission:continuously variable transmission (CVT)
Transmission details ...
Photos
No photos of the New Holland T6.165 Auto Command are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center load sensing
Rear valves:3 to 4
Mid valves:0 to 3
Pump flow:33 gpm
124.9 lpm
Tractor hitch
Rear Type:II
 III/II
Rear lift (at ends):11649 lbs
5283 kg
Front Hitch:optional
Drawbar:Cat. 3
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Front PTO:optional
Dimensions & Tires
Wheelbase:104 inches
264 cm
Suspension Wheelbase:105.7 inches
268 cm
SuperSteer Wheelbase:109.8 inches
278 cm
Weight:10561 to 12514 pounds
Front tire:380/85R28
Rear tire:460/85R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
 200*Optional
Battery CCA:1300
Battery volts:12
