Tractors > Iseki > TG5570

Iseki TG5570

No photo available
2004 -    TG Series
Compact Utility tractor






Production:

Manufacturer:Iseki


Iseki TG5570 Engine:

   Iseki 3.0L 4-cyl diesel
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:II/I
Rear lift (at ends):3924 lbs [1779 kg]
Rear Arms:telescopic link ends


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000 (1.375)


Dimensions & Tires:

Wheelbase:70.7 inches [179 cm]
Weight:4090 to 4442 pounds
Front tire:9.50-18
Rear tire:14.9-28
full dimensions and tires ...


TG5570 Serial Numbers:


- Serial numbers unknown -



Iseki TG5570 Power:

Engine:60 hp [44.7 kW]
PTO (claimed):47 hp [35.0 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.


Hydraulics:

Type:open center
Pump flow:12.8 gpm [48.4 lpm]


Battery:
