Massey-Harris 30 Standard


Massey-Harris 30 Standard tractor photo
1946 - 1952
Standard-tread tractor
Production
ManufacturerMassey-Harris
Standard-tread tractor
Built in Racine, Wisconsin, USA
Variants
30 RCrow-crop
30 STDstandard tread
Massey-Harris 30 Engine
Continential 2.7L 4-cyl gasoline
Fuel tank20 gal
75.7 L
Engine details ...
Massey-Harris 30 Power
Drawbar (claimed)21 hp
15.7 kW
PTO (claimed)33 hp
24.6 kW
Plows2-3
Mechanical
Two-wheel drive
Manual steering
Mechanical brakes
Open operator station
Photos
No photos of the Massey-Harris 30 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear PTO Type540
Dimensions & Tires
Wheelbase79.2 inches
201 cm
Weight3960 lbs
1796 kg
Front tire5x15
Rear tire11x28
Full dimensions and tires ...
30 Serial Numbers
Location:Data plate on the main tractor frame.
19461001
19471002
19482120
19493184
19505388
19517491
19528696

FAQ: How to read a serial number table.
Belt Pulley
Diameter13.5 inches
34 cm
Width6.25 inches
15 cm
RPM838
Speed2,960 ft/min
902.21 meters/min
Electrical
Groundpositive
Battery volts6
References
30 Standard references literature
Power-Plus Tractors published in 1951, by Massey-Harris
