Shibaura SD5040T


Shibaura SD5040T tractor photo
1977 - 1980
SD Series
Compact Utility tractor
Production
Manufacturer:Shibaura
Type:Compact Utility tractor
Variants
SD5000T:2WD
SD5040T:4WD
Shibaura SD5040T Power
Engine:50 hp
37.3 kW
PTO (claimed):44.9 hp
33.5 kW
Shibaura SD5040T Engine
Shibaura 2.1L 4-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:mechanical drum
Cab:Open operator station. Available two-post ROPS and canopy.
Transmission:24-speed gear
Transmission details ...
Photos
No photos of the Shibaura SD5040T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:9.2 gal
34.8 L
Hydraulic system:9.2 gal
34.8 L
Hydraulics
Type:open center
Capacity:9.2 gal
34.8 L
Valves:1 or 2
Pump flow:7.1 gpm
26.9 lpm
Tractor hitch
Rear Type:II/I
Control:position and draft control
Rear lift (at ends):4343 lbs
1969 kg
Power Take-off (PTO)
Rear PTO:transmission
 live*Optional with two-stage clutch.
Rear RPM:540 (1.375)
Engine RPM:557@2400
714@2400
1148@2400
1345@2400
Dimensions & Tires
Wheelbase:73.8 inches
187 cm
Weight:3705 lbs
1680 kg
Front tire:8.00x18
Rear tire:12.4/11-28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:20
Battery volts:12
Battery AH:100
