Tractors > John Deere > 5065E

John Deere 5065E



John Deere 5065E tractor photo
2008 - 2022
Model year
5E Series
Utility tractor
Series map:
5055E
5065E
5075E
55.0hp
65.0hp
75.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Pune, Maharashtra, India
Original price$21,689 (2014 9-speed ROPS 2WD )
$38,549 (2014 12-speed Cab 4WD )
John Deere 5065E Engine
John Deere 2.9L 3-cyl diesel
Fuel tank18 gal (ROPS)
68.1 L
 21.7 gal (cab)
82.1 L
Engine details ...
John Deere 5065E Transmissions
9-speed partially synchronized
12-speed partially synchronized
Transmission details ...
John Deere 5065E Power
Engine (gross)65 hp
48.5 kW
PTO (claimed)53 hp (ROPS)
39.5 kW
 49 hp (cab)
36.5 kW
Mechanical
Two- or four-wheel drive
Steeringhydrostatic power
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional.
Photos
No photos of the John Deere 5065E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves1 or 2
Mid valves0 or 2
Pump flow11.4 gpm
43.1 lpm
Total flow18.2 gpm
68.9 lpm
Steering flow6.8 gpm
25.7 lpm
Tractor hitch
Rear TypeII
Controltop link draft sensing
Rear lift (at 24"/610mm)3192 lbs
1447 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchmechanical
 electro-hydraulic (optional)
Rear PTO Type540 (1.375)
 540/540E (1.375)
Dimensions & Tires
Wheelbase80.7 inches
204 cm
Weight4634 to 5732 pounds
Front tire7.5-16
Rear tire16.9-28 (2WD)
Full dimensions and tires ...
John Deere 5065E attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5065E references literature
5D - 5E Utility Tractors published in 2013, by John Deere*
5D - 5E Utility Tractors published in 2014, by John Deere*
Operator's Manual 5045E, 5055E, 5065E and 5075E Tractors (OMSJ301048) published in 2014
*Publication contains known errors.
