CaseIH Magnum 180 Transmission


CaseIH Magnum 180 tractor photo
2009 - 2025
Model year
Magnum Series
Row-Crop tractor
Series map:
Magnum 180
Magnum 200
180.0hp
200.0hp
Transmission options
19-speed full power shift
continuously variable transmission (CVT)
Transmission
Typefull power shift
Gears19 forward and 6 reverse
Clutchelectro-hydraulic wet disc
Speeds
Magnum 180  full power shift speeds
Transmission
Typecontinuously variable transmission (CVT)
Gearsinfinite forward and reverse
