Challenger MT555D
| | 2012 - 2014 |
| MT500D Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Row-Crop tractor |
| Factories | Beauvais, France
|
| | Jackson, Minnesota, USA
|
| Original price | $146,656 (2013 classic )
|
| $171,007 (2013 deluxe )
|
| $181,317 (2013 deluxe )
|
| Variants |
| 7619 | similar Massey Ferguson model
|
| Challenger MT555D Power |
| Engine | 170 hp
126.8 kW
|
| PTO (claimed) | 140 hp
104.4 kW
|
| Drawbar (tested) | 123.8 hp
92.3 kW
|
| PTO (tested) | 173.3 hp
129.2 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic full locking
|
| Steering | hydrostatic power
|
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic (optional)
|
| | pneumatic (optional)
|
| Cab standard with air-conditioning. AGCO System 150 (optional); AGCOMMAND (optional) |
| Photos |
| No photos of the Challenger MT555D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 114 gal
431.5 L
|
| Exhaust fluid (DEF) | 11 gal
41.6 L
|
| Hydraulic system | 26.4 gal
99.9 L
|
| Hydraulics |
| Type | closed center load sensing (CCLS)
|
| Capacity | 26.4 gal
99.9 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 2 to 4
|
| SCV flow | 24.3 gpm
92.0 lpm
|
| Total flow | 29 gpm
109.8 lpm
|
| | 39 gpm (optional)
147.6 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Control | electronic lower link draft control
|
| Rear lift (at 24"/610mm) | 12500 lbs (AutoPower)
5670 kg
|
| | 11650 lbs (CVT)
5284 kg
|
| Drawbar | Cat. 2
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear RPM | 540/1000
|
| | 540/540E/1000
|
| | 540E/1000E/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 175
|
| | 240 *Total capacity with dual 120A alternator option.
|
| Batteries | 2
|
| Battery CCA | 600
|
| Battery volts | 12
|
| References |
 |
| Challenger MT500D Series published in 2011, by AGCO |
| Challenger MT500D Series published in 2013, by AGCO |
| Page information |
| Contact: Peter Easterlund |
| Updated on October 21, 2022 |
| Copyright 2022 TractorData LLC |
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
