Tractors > Challenger > MT755D

Challenger MT755D

Challenger MT755D tractor photo
2012 - 2013   MT700D Series
Agricultural Crawler tractor
Previous model:Challenger MT755C
Next model:Challenger MT755E






Production:

Manufacturer:AGCO
Factory:Jackson, Minnesota, USA


Challenger MT755D Engine:

   AGCO POWER 8.4L 6-cyl diesel
full engine details ...


Capacity:

Fuel:109 gal [412.6 L]
 169 gal [639.7 L] (wide gauge)
Exhaust fluid (DEF):18 gal [68.1 L]


3-Point Hitch:

Rear Type:III/IIIN
Rear lift:16000 lbs [7257 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:1000 (1.75)


Dimensions & Tires:

Weight:31075 lbs [14095 kg]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


MT755D Serial Numbers:


- Serial numbers unknown -



Challenger MT755D Power:

Engine (gross):327 hp [243.8 kW]
PTO (claimed):260 hp [193.9 kW]
Drawbar (tested):251.60 hp [187.6 kW]
PTO (tested):317.51 hp [236.8 kW]
power test details ...


Mechanical:

Chassis:crawler
Steering:electro-hydraulic differential
Brakes:hydraulic wet disc
Cab:Cab standard.


Hydraulics:

Type:closed-center pressure-flow compensated (PFC)
Pressure:2900 psi [200.0 bar]
Valves:4 to 6
Pump flow:43.5 gpm [164.6 lpm]
 59 gpm [223.3 lpm] (optional)
SCV flow:36 gpm [136.3 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:300 (2x 150amp)


Battery:

Number:2
Volts:12
