| | 2006 - 2015 |
| 500 Series | | Compact Utility tractor |
|
| Transmissions overview |
| 16-speed sync shuttle |
| hydrostatic |
| Transmission |
| Type: | sync shuttle
|
| Gears: | 16 forward and reverse
|
| Clutch: | single dry disc
|
| Oil capacity: | 36.8 qts
34.8 L
|
| Four synchronized gears (1-4) in four ranges with synchronized shuttle shift. Tractor must be stopped to shift range. |
| Speeds |
| Reverse speeds are 15% slower than forward. |
|
| Transmission |
| Type: | hydrostatic
|
| Gears: | infinite forward and reverse
|
| Hydrostatic transmission first offered in 2011. |
| Page information |
| Last update: | May 25, 2017
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
