John Deere 5075M

John Deere 5075M tractor photo
2008 - 2017   5M Series
Model years
Utility tractor
Series next:John Deere 5085M
Series back:John Deere 5065M






Production:

Manufacturer:John Deere
Factory:Augusta, Georgia, USA
Original price (USD)
   $44,487 (2012 )
   $47,423 (2014 )


John Deere 5075M Engine:

   John Deere 3.0L 5-cyl diesel
full engine details ...


Capacity:

ROPS Fuel:21 gal [79.5 L]
Cab Fuel:30 gal [113.6 L]


3-Point Hitch:

Rear Type:2/1
Control:position control and lower-link draft sensing


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540/540E
 540 (SyncShuttle)


Dimensions & Tires:

Wheelbase:85.6 inches [217 cm]
Weight:6017 to 7800 pounds
Front tire:11L-15
Rear tire:16.9-30 (2WD)
full dimensions and tires ...


John Deere 5075M attachments:

 front-end loader
all 5075M attachments ...


5075M Serial Numbers:

Location:Serial number plate on the right side of the tractor frame, above the front axle.

- Serial numbers unknown -



John Deere 5075M Power:

Engine (gross):75 hp [55.9 kW]
PTO (claimed):60 hp [44.7 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post foldable ROPS with flat operation platform. Optional isolated platform. Optional cab with air-conditioning. Optional deluxe cab with premium sound package and sunroof.


Hydraulics:

Type:open center
Pressure:2828 psi [195.0 bar]
Rear valves:2 ro 3
Mid valves:2 or 3
Pump flow:14.6 gpm [55.3 lpm]
Total flow:20.9 gpm [79.1 lpm]
Steering flow:6.3 gpm [23.8 lpm]
Steering press.:2030 psi [140.0 bar]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:70 (ROPS)
 90 (cab)


Battery:

Number:1
Volts:12
