John Deere 6110J Transmission


John Deere 6110J tractor photo
2010 -
6J Series
Utility tractor
Series:6110J6125J
Transmissions overview
12-speed fully synchronized
16-speed partial power shift
Transmission
Transmission:John Deere SyncroPlus
Type:fully synchronized
Gears:12 forward and 4 reverse
Clutch:hydraulic wet discs
Oil type:
JD Hy-Gard

Three synchronized gears (1-3) in four synchronized ranges (A-D).
Speeds
With 23.1-30 R1 rear tires.
6110J SyncroPlus fully synchronized speeds
Transmission
Transmission:John Deere PowrQuad
Type:partial power shift
Gears:16 forward and reverse
Clutch:hydraulic wet discs
Oil type:
JD Hy-Gard

Four power shift gears (1-4) in four synchronized ranges (A-D).
Speeds
With 23.1-30 R1 rear tires. Reverse speeds are 15% faster than forward.
6110J PowrQuad partial power shift speeds
