Tractors > John Deere > 5100GF

John Deere 5100GF - engine

No photo available
2009 - 2013   5G Series
Orchard/Vineyard tractor
Series back:John Deere 5090GF
more John Deere 5100GF specifications...






Engine Detail:

 John Deere 4045HAT82
 turbocharged aftercooled diesel
 4-cylinder
 liquid-cooled
 275.5 ci [4.5 L]
Bore/Stroke:4.19x5.00 inches [106 x 127 mm]
Emissions:Stage IIIA
Power:100 hp [74.6 kW]
Compression:19.0:1
Rated RPM:2300
Torque:276.6 lb-ft [375.1 Nm]
Torque RPM:1600
Firing order:1-3-4-2
Starter:electric
Starter volts:12
Starter power:3.8 hp [2.8 kW]
Oil capacity:8.5 qts [8.0 L]
Oil change:500 h
Coolant capacity:11 qts [10.4 L]
 13.7 qts [13.0 L] (cab)
Coolant change:2000 h
Intake valve clearance:0.014 inches [0.356 mm]
Exhaust valve clearance:0.018 inches [0.457 mm]
