Tractors > AGCO > RT140A

AGCO RT140A

AGCO RT140A tractor photo
2006 - 2011   RT-A Series
Row-Crop tractor
Previous model:AGCO RT140
Series next:AGCO RT155A
Series back:AGCO RT120A






Production:

Manufacturer:AGCO
Factory:Beauvais, France


AGCO RT140A Engine:

   SisuDiesel 6.6L 6-cyl diesel
full engine details ...


Capacity:

Fuel:100 gal [378.5 L]


3-Point Hitch:

Rear Type:3/3N
Control:electronic position and lower-link draft control
Rear lift:16,500 lbs [7484 kg]
CVT Rear lift:16,140 lbs [7321 kg]
Front Hitch:optional
Front lift:8,800 lbs [3991 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/540E/1000
Front PTO:2/3 (optional)
Front RPM:1000


Dimensions & Tires:

2WD Wheelbase:118.6 inches [301 cm]
4WD Wheelbase:117.9 inches [299 cm]
Weight:14300 to 15100 pounds
Front tire:10.00x16
Rear tire:18.4R42 (2WD)
full dimensions and tires ...


RT140A Serial Numbers:


- Serial numbers unknown -



AGCO RT140A Power:

Engine:170 hp [126.8 kW]
PTO (claimed):140 hp [104.4 kW]
Drawbar (tested):127.7 hp [95.2 kW]
PTO (tested):179.7 hp [134.0 kW]
power test details ...


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:front and rear
Steering:hydrostatic power
Brakes:hydraulic wet disc
Cab:Cab standard. Optional Airmaxx pneumatic cab suspension and automatic climate control.


Hydraulics:

Type:closed center pressure flow compensated (PFC)
Pressure:2900 psi [200.0 bar]
Valves:3 to 5
Total flow:29 gpm [109.8 lpm]
 39 gpm [147.6 lpm] (optional)


Electrical:

Ground:negative
Charging system:alternator
Charging amps:120
 150 (optional)


Battery:

Number:2
Cold-cranking amps:550
Volts:12
