Iseki TA545


Iseki TA545 tractor photo
1993 - 1999
TA500 Series
Compact Utility tractor
Series:TA537TA545TA550
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Factory:Japan
Iseki TA545 Power
Engine:45 hp
33.6 kW
Iseki TA545 Engine
Isuzu 2.5L 4-cyl diesel
Fuel tank:13.5 gal
51.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:mechanical wet disc
Cab:Two-post folding ROPS. Cab available with air-conditioning.
Transmission:16-speed shuttle
Transmission details ...
Photos
No photos of the Iseki TA545 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2400 psi
165.5 bar
Total flow:8.4 gpm
31.8 lpm
Steering flow:6 gpm
22.7 lpm
Tractor hitch
Rear Type:II
Rear lift (at ends):4189 lbs
1900 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:77.6 inches
197 cm
Weight:3880 lbs
1759 kg
Front tire:7.5x16
2WD Rear tire:14.9x28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:45
Battery volts:12
Battery AH:110
