Iseki TA537


Iseki TA537 tractor photo
1993 - 1999
TA500 Series
Compact Utility tractor
Series map:
TA530
TA537
TA545
22.4kw
27.6kw
33.6kw
Production
ManufacturerIseki
Compact Utility tractor
Built in Japan
Iseki TA537 Engine
Isuzu 2.0L 4-cyl diesel
Fuel tank12.7 gal
48.1 L
Engine details ...
Iseki TA537 Power
Engine37 hp
27.6 kW
Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post folding ROPS. Cab available with air-conditioning.
Photos
No photos of the Iseki TA537 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2200 psi
151.7 bar
Total flow7.7 gpm
29.1 lpm
Steering flow6 gpm
22.7 lpm
Tractor hitch
Rear TypeII
Rear lift (at ends)3,968 lbs
1799 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear RPM540/1000
Dimensions & Tires
Wheelbase74.8 inches
189 cm
Weight3,384 lbs
1534 kg
Front tire8x18
Rear tire13.6-26
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
Battery volts12
Battery AH45
References
TA537 references literature
TA Series published in 1993, by Iseki
