Iseki TG333


Iseki TG333 tractor photo
???? - 2004
TG Series
Compact Utility tractor
Series:TG313TG333TG353
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Iseki TG333 Power
Engine:33 hp
24.6 kW
PTO (claimed):31 hp
23.1 kW
Iseki TG333 Engine
Iseki 1.5L 3-cyl diesel
Fuel tank:9.2 gal
34.8 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:rear standard
Steering:power
Cab:Two-post ROPS.
Transmission:16-speed shuttle
Transmission details ...
Photos
No photos of the Iseki TG333 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:7.7 gpm
29.1 lpm
Tractor hitch
Rear Type:I
Control:position control
Power Take-off (PTO)
Rear RPM:540
Dimensions & Tires
Wheelbase:70.1 inches
178 cm
Weight:3373 lbs
1529 kg
Front tire:8-16
Rear tire:13.6-24
Full dimensions and tires ...
