Tractors > Iseki > TL2300

Iseki TL2300

Iseki TL2300 tractor photo
1980 - 1985   TL Series
Compact Utility tractor
Series next:Iseki TL2500
Series back:Iseki TL2100






Production:

Manufacturer:Iseki


Variants:

TL2300F:4WD


Iseki TL2300 Engine:

   Isuzu 1.3L 3-cyl diesel
full engine details ...


Capacity:

Fuel:7.1 gal [26.9 L]


3-Point Hitch:

Rear Type:JIS1


Power Take-off (PTO):

Rear RPM:540 (1.375)
Engine RPM:553@2600
731@2600
906@2600
1280@2600


Dimensions & Tires:

Wheelbase:62.2 inches [157 cm]
Weight:2094 to 2293 pounds
Front tire:4.00-15
2WD Rear tire:9.5-24
full dimensions and tires ...


TL2300 Serial Numbers:


how to read serial numbers...



Iseki TL2300 Power:

Engine:23 hp [17.2 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
