Iseki TXG23
| | 2008 - ???? |
| Compact Utility tractor |
|
| Production |
| Manufacturer: | Iseki
|
| Type: | Compact Utility tractor
|
| Iseki TXG23 Power |
| Engine: | 22 hp
16.4 kW
|
| PTO (claimed): | 17.5 hp
13.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | mechanical wet disc
|
| Cab: | ROPS
|
 Transmission details ... |
| Photos |
| No photos of the Iseki TXG23 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Total flow: | 6.1 gpm
23.1 lpm
|
| Steering flow: | 2 gpm
7.6 lpm
|
| Steering press.: | 1209 psi
83.4 bar
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 1,190 lbs
539 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540
|
| Mid RPM: | 2000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 40
|
| Battery CCA: | 390
|
| Battery volts: | 12
|
| Battery AH: | 36
|
| Page information |
| Last update: | March 19, 2020
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
