Tractors > Iseki > TG5390

Iseki TG5390

Iseki TG5390 tractor photo
2004 -    TG Series
Compact Utility tractor
Series next:Iseki TG5470
Series back:Iseki TG5330






Production:

Manufacturer:Iseki


Iseki TG5390 Engine:

   Iseki 1.5L 3-cyl diesel
full engine details ...


Capacity:

Fuel:10.6 gal [40.1 L]


3-Point Hitch:

Rear Type:I
Rear lift (at ends):2,800 lbs [1270 kg]
Rear lift (at 24"/610mm):2,138 lbs [969 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000
Mid RPM:2000


Dimensions & Tires:

Wheelbase:69.7 inches [177 cm]
Weight:2,888 lbs [1309 kg]
Front tire:7-16
Rear tire:12.4-24
full dimensions and tires ...


TG5390 Serial Numbers:


- Serial numbers unknown -



Iseki TG5390 Power:

Engine:37.5 hp [28.0 kW]
PTO (claimed):31 hp [23.1 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:wet discs
Cab:Two-post ROPS.


Hydraulics:

Pressure:2276 psi [156.9 bar]
Total flow:9.1 gpm [34.4 lpm]
Steering flow:4.9 gpm [18.5 lpm]
 6 gpm [22.7 lpm] (with powershift)
Steering press.:1138 psi [78.5 bar]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:40


Battery:

Number:1
Cold-cranking amps:630
Volts:12
Amp-hours:55
