Farmtrac 80


Farmtrac 80 tractor photo
2002 - 2003
Utility tractor
Production
Manufacturer:Farmtrac
Type:Utility tractor
Variants
80DT:4WD
Farmtrac 80 Power
Engine:72.4 hp
54.0 kW
PTO (claimed):64.8 hp
48.3 kW
Farmtrac 80 Engine
Perkins 4.2L 4-cyl diesel
Fuel tank:21 gal
79.5 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:planetary
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Open operator station.
Transmission:12-speed
Transmission details ...
Photos
No photos of the Farmtrac 80 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2490 psi
171.7 bar
Valves:1 or 2
Pump flow:11 gpm
41.6 lpm
Tractor hitch
Rear Type:II
Rear lift (at ends):5300 lbs
2404 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@2115
Dimensions & Tires
2WD Wheelbase:93 inches
236 cm
4WD Wheelbase:91 inches
231 cm
Weight:5675 lbs
2574 kg
Front tire:7.50-16
2WD Rear tire:16.9-30
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:55
Battery volts:12
Battery AH:88
