Tractors > John Deere > 5045E

John Deere 5045E - engine

John Deere 5045E tractor photo
2008 - 2017   5E Series
Model years
Utility tractor
Series next:John Deere 5055E
more John Deere 5045E specifications...






Engine Detail:

 John Deere PowerTech 3029T
 turbocharged diesel
 3-cylinder
 liquid-cooled
 179 ci [2.9 L]
Bore/Stroke:4.19x4.33 inches [106 x 110 mm]
Rated Power (EC 97/98):45 hp [33.6 kW]
Air cleaner:two paper elements
Rated RPM:2400
Idle RPM:800-2600
Operating RPM:1700-2400
Torque:135.7 lb-ft [184.0 Nm]
Torque RPM:1700
Firing order:1-2-3
Starter volts:12
Oil capacity:9 qts [8.5 L]
Oil change:100 h
Coolant capacity:10 qts [9.5 L]
Intake valve clearance:0.014 inches [0.356 mm]
Exhaust valve clearance:0.018 inches [0.457 mm]
