Tractors > Bobcat > CT230
      -Brand search:


    Bobcat CT230

    Bobcat CT230 tractor photo
    2008 - 2013
    Compact Utility tractor
    Larger:Bobcat CT235
    Smaller:Bobcat CT225






    Production:

    Distributor:Bobcat
    Manufacturer:Daedong
    Factory:Daegu, South Korea


    Bobcat CT230 Engine:

       Daedong 1.5L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:7.9 gal [29.9 L]


    3-Point Hitch:

    Rear Type:1
    Rear lift (at 24"/610mm):1,225 lbs [555 kg]
     1,400 lbs [635 kg] (with loader)


    Power Take-off (PTO):

    Rear PTO:live
    Rear RPM:540
    Mid PTO:optional
    Mid RPM:2000


    Dimensions & Tires:

    Wheelbase:66.1 inches [167 cm]
    Weight:3,056 lbs [1386 kg]
    Front tire:25x8.5-14
    Rear tire:15x19.5
    full dimensions and tires ...


    Bobcat CT230 attachments:

     mowing deck
     snowblower
     front-end loader
     backhoe
    all CT230 attachments ...


    CT230 Serial Numbers:


    - Serial numbers unknown -



    Bobcat CT230 Power:

    Engine:30 hp [22.4 kW]
    PTO (claimed):22 hp [16.4 kW]


    Mechanical:

    Chassis:4x4 MFWD 4WD
    Steering:hydrostatic power
    Cab:folding ROPS


    Hydraulics:

    Valves:1 or 2
    Pump flow:8.2 gpm [31.0 lpm]
    Total flow:12.7 gpm [48.1 lpm]
    Steering flow:4.5 gpm [17.0 lpm]
