Allis Chalmers HD16AC


Allis Chalmers HD16AC tractor photo
1955 - 1970
Agricultural Crawler tractor
Production
ManufacturerAllis Chalmers
Agricultural Crawler tractor
Built in Springfield, Illinois, USA
Variants
HD16A6-speed
HD16ACtorque converter
Allis Chalmers HD16AC Engine
Allis Chalmers 13.8L 6-cyl diesel
Fuel tank100 gal
378.5 L
Engine details ...
Allis Chalmers HD16AC Power
Engine (gross)170 hp
126.8 kW
Engine (net)150 hp
111.9 kW
Drawbar (claimed)125 hp
93.2 kW
Drawbar (tested)104.96 hp
78.3 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringhydraulic clutches
Contracting band brakes
Open operator station.
Photos
No photos of the Allis Chalmers HD16AC are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tracks
Weight31600 lbs
14333 kg
20-inch tracks
Full dimensions and tracks ...
References
HD16AC references literature
Engineering-in-Action published in 1956, by Allis Chalmers
