McCormick-Deering B-450
| | 1958 - 1970 |
| Standard-tread tractor |
|
| Production |
| Manufacturer: | McCormick-Deering (a part of International Harvester)
|
| Type: | Standard-tread tractor
|
| Factory: | Doncaster, England
|
| Total built: | 28,290
|
| McCormick-Deering B-450 Power |
| Engine: | 55 hp
41.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | manual
|
| Cab: | Open operator station.
|
| Transmission: | 5-speed gear
|
 Transmission details ... |
| Capacity |
| Fuel: | 20.9 gal
79.1 L
|
| Hydraulic system: | 3.6 gal
13.6 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 3.6 gal
13.6 L
|
| Pressure: | 2000 psi
137.9 bar
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift: | 6240 lbs
2830 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 555@1500
|
| B-450 Serial Numbers |
| 1958: | 501
|
| 1959: | 981
|
| 1960: | 3282
|
| 1961: | 6202
|
| 1962: | 9307
|
| 1963: | 12428
|
| 1964: | 15735
|
| 1965: | 18325
|
| 1966: | 21280
|
| 1967: | 23795
|
| 1968: | 25488
|
| 1969: | 36846
|
| 1970: | 27953
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 11 inches
27 cm
|
| RPM: | 929.6
|
| Speed: | 2677 ft/min
815.95 meters/min
|
