Nebraska Tractor Test 609: |
|
|
| Test Date: | March 18 - April 5, 1957
|
| Type: | Diesel Torque Amplifier 2WD
|
| Belt power (max): | 38.65 hp [28.8 kW]
|
| Belt fuel use (max): | 2.6 gal/hour [9.8 l/hour]
|
| Drawbar power (max): | 27.76 hp [20.7 kW]
|
| Drawbar fuel use (max): | 2.2 gal/hour [8.3 l/hour]
|
| Drawbar pull (max): | 6,039 lbs [2739 kg]
|
| Max pull gear: | 1-TA
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 611: |
|
|
| Test Date: | April 1 - 13, 1957
|
| Type: | Gasoline Torque Amplifier 2WD
|
| Belt power (max): | 39.31 hp [29.3 kW]
|
| Belt fuel use (max): | 3.2 gal/hour [12.1 l/hour]
|
| Drawbar power (max): | 28.76 hp [21.4 kW]
|
| Drawbar fuel use (max): | 2.9 gal/hour [11.0 l/hour]
|
| Drawbar pull (max): | 6,457 lbs [2928 kg]
|
| Max pull gear: | 1-TA
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 622: |
|
|
| Test Date: | May 22 - 29, 1957
|
| Type: | LP gas Torque Amplifier 2WD
|
| Belt power (max): | 39.34 hp [29.3 kW]
|
| Belt fuel use (max): | 4.1 gal/hour [15.5 l/hour]
|
| Drawbar power (max): | 30.07 hp [22.4 kW]
|
| Drawbar fuel use (max): | 3.6 gal/hour [13.6 l/hour]
|
| Drawbar pull (max): | 6,395 lbs [2900 kg]
|
| Max pull gear: | 1-TA
|
| Test report: | PDF file
|
| |
