Tractors > Cub Cadet > 7275

Cub Cadet 7275 - engine

Cub Cadet 7275 tractor photo
1996 - 1997   7000 Series
Compact Utility tractor
Series back:Cub Cadet 7274
more Cub Cadet 7275 specifications...






Engine Detail:

 Mitsubishi K3M
 diesel
 3-cylinder
 liquid-cooled overhead valve (OHV)
 91.3 ci [1.5 L]
Bore/Stroke:3.307x3.543 inches [84 x 90 mm]
Power:27 hp [20.1 kW]
Fuel system:direct injection
Air cleaner:dry
Compression:18:1
Rated RPM:2500
Idle RPM:970-2750
Firing order:1-3-2
Starter volts:12
Oil capacity:5 qts [4.7 L]
Oil change:100 h
Coolant capacity:6.7 qts [6.3 L]
Coolant change:1000 h
Intake valve clearance:0.010 inches [0.254 mm] *Cold
Exhaust valve clearance:0.010 inches [0.254 mm] *Cold
