Tractors > Challenger > MT855

Challenger MT855

Challenger MT855 tractor photo
2002 - 2004   MT800 Series
Agricultural Crawler tractor
Series next:Challenger MT865
Series back:Challenger MT845






Production:

Manufacturer:AGCO
Factory:USA


Challenger MT855 Engine:

   Caterpillar 14.6L 6-cyl diesel
full engine details ...


Capacity:

Fuel:305 gal [1154.4 L]
 330 gal [1249.1 L] *Optional
Hydraulic system:70 gal [264.9 L]


3-Point Hitch:

Rear Type:IVN
Rear lift:19500 lbs [8845 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:1000 (1.75)


Dimensions & Tires:

Wheelbase:118.1 inches [299 cm]
Weight:41000 to 50000 pounds
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


MT855 Serial Numbers:

Location:Serial number plate on the left side of the tractor frame.
2002: BACC20000
2003: BCC30000
2004: BCC40000

how to read serial numbers...



Challenger MT855 Power:

Engine (gross):450 hp [335.6 kW]
PTO (claimed):374 hp [278.9 kW]
Drawbar (tested):346.83 hp [258.6 kW]
PTO (tested):452.31 hp [337.3 kW]
power test details ...


Mechanical:

Chassis:crawler
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning.


Hydraulics:

Type:closed center load sensing
Capacity:70 gal [264.9 L]
Pressure:2900 psi [200.0 bar]
Rear valves:4 to 6
Pump flow:43.5 gpm [164.6 lpm]
 59 gpm [223.3 lpm] *Optional
SCV flow:30 gpm [113.6 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:160


Battery:

Number:4
Volts:12
