Challenger MT875B

Challenger MT875B tractor photo
2005 - 2008   MT800B Series
Agricultural Crawler tractor
Next model:Challenger MT875C
Series back:Challenger MT865B






Production:

Manufacturer:AGCO


Challenger MT875B Engine:

   Caterpillar 18.1L 6-cyl diesel
full engine details ...


Capacity:

Fuel:330 gal [1249.1 L]


Dimensions & Tires:

Wheelbase:118 inches [299 cm]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


MT875B Serial Numbers:


- Serial numbers unknown -



Challenger MT875B Power:

Engine:570 hp [425.0 kW]
Drawbar (tested):431.02 hp [321.4 kW]
power test details ...


Mechanical:

Chassis:crawler
Cab:Cab standard.


Hydraulics:

Type:closed center PFC
Pressure:2900 psi [200.0 bar]
Valves:4
 6 (optional)
Total flow:43.5 gpm [164.6 lpm]
 59 gpm [223.3 lpm] (optional)


Electrical:

Ground:negative
Charging amps:185


Battery:

Number:4
Cold-cranking amps:1000
Volts:12
