Allis Chalmers HD11 Tests


Allis Chalmers HD11 tractor photo
1955 - 1966
Agricultural Crawler tractor
Series map:
HD11
110.0hp
Nebraska Tractor Test 581
HD11 fuel use from test 581
Nebraska Tractor Test 581
Diesel 6-speed crawler
July 9 - 13, 1956
Link: Nebraska Tractor Test 581 file
Belt power (max)89.75 hp
66.9 kW
Belt fuel use (max)6.9 gal/hour
26.1 l/hour
Drawbar performance
Max power73.8 hp
55.0 kW
Max pull20468 lbs
9284 kg
Gear 1 used for pull test.
