Volvo T25


Volvo T25 tractor photo
1952 - 1959
T20 Series
Standard-tread tractor
Production
ManufacturerVolvo
Standard-tread tractor
Variants
T24kerosene
T25gasoline
Volvo T25 Engine
Volvo 2.2L 4-cyl gasoline
Engine details ...
Volvo T25 Power
Engine30.6 hp
22.8 kW
PTO (claimed)26.1 hp
19.5 kW
Mechanical
Two-wheel drive
Open operator station.
Photos
No photos of the Volvo T25 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel11.9 gal
45.0 L
Hydraulic system1.6 gal
6.1 L
Hydraulics
Capacity1.6 gal
6.1 L
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM540@1700
Dimensions & Tires
Wheelbase69.7 inches
177 cm
Weight3461 lbs
1569 kg
Front tire5.50-16
Rear tire11-28
Full dimensions and tires ...
Electrical
Charging systemgenerator
Battery volts6
Battery AH85
References
T25 references literature
T24-T25 published in 1955, by Volvo
Instruktionsbok Traktor T24-25 (SS 1076/1) published in 1952
