Volvo T22


Volvo T22 tractor photo
1947 - 1952
Standard-tread tractor
Production
ManufacturerVolvo
Standard-tread tractor
Volvo T22 Engine
Volvo 2.0L 4-cyl kerosene
Fuel tank11.9 gal
45.0 L
Aux. fuel1 gal
3.8 L
Engine details ...
Volvo T22 Power
Engine22 hp
16.4 kW
Mechanical
Two-wheel drive
Open operator station.
Photos
No photos of the Volvo T22 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM540@1400
Dimensions & Tires
Wheelbase66.9 inches
169 cm
Weight2767 lbs
1255 kg
Front tire5.00-15
Rear tire10-28
Full dimensions and tires ...
References
T22 references literature
T22 published in 1949, by Volvo
