SAME Diamond 265


SAME Diamond 265 tractor photo
2004 - 2006
Diamond Series
Row-Crop tractor
Series map:
Diamond 215
Diamond 265
169.3kw
206.6kw
Production
ManufacturerSAME
Row-Crop tractor
SAME Diamond 265 Engine
Deutz 7.1L 6-cyl diesel
Fuel tank145.3 gal
550.0 L
Engine details ...
SAME Diamond 265 Power
Engine (gross)277 hp
206.6 kW
Engine (net)262 hp
195.4 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic
 pneumatic
Cab standard with air-conditioning.
Photos
No photos of the SAME Diamond 265 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typevariable displacement load-sensing
Pump flow31.7 gpm
120.0 lpm
Tractor hitch
Rear lift23152 lbs
10501 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear RPM540E/1000
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front RPM1000
Dimensions & Tires
Wheelbase121.6 inches
308 cm
Weight19952 lbs
9050 kg
Rear tire710/70R42
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
Diamond 265 references literature
Diamond 215 - 265 published in 2004, by SAME
