SAME Diamond 215
|
|
| Production | |
| Manufacturer | SAME |
| Row-Crop tractor | |
| SAME Diamond 215 Engine | |
| Deutz 7.1L 6-cyl diesel | |
| Fuel tank | 95.1 gal 360.0 L |
| 145.3 galOptOptional 550.0 L | |
 Engine details ... | |
| SAME Diamond 215 Transmission | |
| 40-speed four-speed power shift | |
 Transmission details ... |
| SAME Diamond 215 Power | |
| Engine (gross) | 227 hp 169.3 kW |
| Engine (net) | 211 hp 157.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic |
| pneumatic | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the SAME Diamond 215 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | variable displacement load-sensing |
| Pump flow | 31.7 gpm 120.0 lpm |
| Tractor hitch | |
| Rear lift | 23152 lbs 10501 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear RPM | 540E/1000 |
| Front PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Front RPM | 1000 |
| Dimensions & Tires | |
| Wheelbase | 121.6 inches 308 cm |
| Weight | 18541 lbs 8410 kg |
| Rear tire | 710/70R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Diamond 215 - 265 published in 2004, by SAME |
