SAME Titan 160
| | 1991 - 1998 |
| Titan Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | SAME
|
| Type: | Row-Crop tractor
|
| SAME Titan 160 Power |
| Engine: | 159 hp
118.6 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | electro-hydraulic front and rear
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Trailer brakes: | hydraulic
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | 27-speed power shift
|
 Transmission details ... |
| Photos |
| No photos of the SAME Titan 160 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow: | 15.9 gpm
60.2 lpm
|
| Tractor hitch |
| Rear lift: | 15432 lbs
6999 kg
|
| | 18960 lbs
8600 kg *Optional
|
| Front lift: | 5071 lbs
2300 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic wet disc
|
| Rear RPM: | 540/1000
|
| Front PTO: | independent*Optional
|
| Front RPM: | 1000
|
| Page information |
| Last update: | June 13, 2022
|
| Copyright: | Copyright 2022 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
