Tractors > SAME > Argon 60

SAME Argon 60



SAME Argon 60 tractor photo
1993 - 2001
Argon Series
Utility tractor
Series map:
Argon 50
Argon 60
Argon 70
37.0kw
44.0kw
51.5kw
Production
ManufacturerSAME
Utility tractor
Variants
Argon F 65orchard
564-60 Cronosimilar Lamborghini model
H-306 XEsimilar Hurlimann model
5660similar AGCO Allis model
SAME Argon 60 Engine
SAME 3.0L 3-cyl diesel
Fuel tank15.3 gal
57.9 L
Engine details ...
SAME Argon 60 Transmissions
8-speed mechanical shuttle
12-speed creeper
16-speed
24-speed creeper
Transmission details ...
SAME Argon 60 Power
Engine59 hp
44.0 kW
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
Four-post ROPS.
Photos
No photos of the SAME Argon 60 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves2 or 3
Pump flow8.7 gpm
32.9 lpm
Tractor hitch
Rear TypeII
Rear lift6526 lbs
2960 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/540E
 540/1000
 540/540E
 1000
Dimensions & Tires
2WD Wheelbase82.9 inches
210 cm
4WD Wheelbase80.9 inches
205 cm
Weight4542 to 5071 pounds
Front tire7.50-16
2WD Rear tire420/70R28
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
Argon 60 references literature
Argon 50-60-70 published in 1999, by SAME
Argon 50-60-70 published in 2001, by SAME
Argon 50-60-70 published in 2003, by SAME
